microphone
Electret Condenser Microphone Capsule
Electret condenser microphone capsule, 34mm large diaphragm, double-sided gold-plated film, 20Hz-20kHz, 48V for professional studio recording.
TypeElectret Condenser Microphone
Power48V Phantom
Diaphragm34mm Gold-Plated
ApplicationStudio Recording, Broadcast, DIY
Capacitance60pF
DirectivityCardioid / F-8 / Omni
Sensitivity−40dB
Frequency Response20Hz - 20kHz
Size(min-max)-40dB
1. Large 34mm Diaphragm: Double-sided gold-plated film captures rich harmonic detail for professional recordings.
2. Studio-Grade Performance: 20Hz-20kHz response with high SNR for broadcast and vocal applications.
3. Multiple Polar Patterns: Cardioid, figure-8 and omnidirectional options available for versatile recording.
4. 48V Phantom Compatible: Integrates with standard studio microphone preamps and interfaces.
5. Precision Construction: Tight tolerance assembly ensures consistent performance across units.
Application Scenes
Studio Recording, Broadcast, DIY
| Type | Electret Condenser Microphone |
|---|---|
| Power | 48V Phantom |
| Diaphragm | 34mm Gold-Plated |
| Application | Studio Recording, Broadcast, DIY |
| Capacitance | 60pF |
| Directivity | Cardioid / F-8 / Omni |
| Sensitivity | −40dB |
| Frequency Response | 20Hz - 20kHz |
| Size(min-max) | -40dB |
Request a Quote
Tell us about your requirements and our sales team will reply within 24 hours.
FAQ
Frequently Asked Questions
Q: How is the microphone capsule packaged for transport?
Capsules are individually packed in anti-static bags with foam cushioning in cartons. Custom packaging with your brand is available for bulk orders.
Q: Can you provide a matched pair?
Yes, we can match pairs by sensitivity and frequency response for stereo recording applications.
Q: What is the output impedance?
Output impedance ranges from 2.2K Ohm for electret to 150-600 Ohm for dynamic capsules. Custom values are available.
